Product Details:
|
| Model: | CZC7 24V/35A | Type: | Automatic Battery Charger |
|---|---|---|---|
| Output Voltage: | 24V | Current: | 35A |
| Phase: | Single Phase | Application: | Stacker, Pallet Truck, Electric Vehicle |
| Brand: | LAKER | Warranty: | One Year |
| Size: | 200×365×140mm | Weigjt: | 6.6kg |
| High Light: | fork truck battery charger,lorry battery charger |
||
35A 24 Volt Forklift Battery Charger High Frequency For Small Size Batteries
| Type | Lead Acid Battery Charger |
| Technology | High Frequency Automatic Charger |
| Model | CZC7 24V/35A |
| Phase | Single Phase 220V |
| Battery parameter | 24v 200Ah-280Ah |
Introduction:
CZC7 series automatic charger is an advanced Hi-Tech product with strong functions and smart shape. It is featured with small size, light weight, easy operated, high charging efficiency and high reliability ; It combines the high frequency technology with micro-processor controlling technology in one unit to reach the best charging result for the battery, effectively to prolong the battery set’s working cycle life, all the charging process is automatically executed according to the program without the operator on duty.
Application:
Ideal charging equipment for electric pallet truck, electric mover, electric lift, electric tour car and various of electric power driven vehicles.
Product Catalogs:
|
Type, data item |
CZC7- 20A/24V |
CZC7- 25A/24V |
CZC7- 30A/24V |
CZC7- 35A/24V |
CZC7- 20A/48V |
CZC7- 40A/24V |
|||||
| Input Volt. V,Hz | 1Ph.220-240V 50～60Hz | ||||||||||
| Input current A | 4 | 5 | 6 | 7 | 8 | 8 | |||||
| Charge.Current A | 20 | 25 | 30 | 35 | 20 | 40 | |||||
| Output Power kW | 0.72 | 0.9 | 1.08 | 1.26 | 1.44 | 1.44 | |||||
|
Charge.Range V Ah |
24 116-160 |
24 145-200 |
24 174-240 |
24 200-280 |
48 116-160 |
24 230-320 |
|||||
| Size mm | 200×365×140 | 220x405x140 |
220×405 ×140 |
||||||||
| Net weight kg | 6.6 | 8.3 | 8.3 | ||||||||
Product Features:
1. Single Chip Microcomputer (SCM) according to the lead-acid batteries tolerance current capacity,life curve,gas analysis point and other information to complete the full charge of the whole process.
2. The battery having the environmental temperature compensation function to ensure that the temperature of the weather conditions,can automatically resist over-charge and under-charge.
3. With pulse charging function,the battery is filled with the premise of ensuring the best life of the battery.
4. The battery also has manual EQU charging function.
5. After three paint processing and dustproof design, the reliability of the operation is improved.
6. With digital display function,it can display online charging current,voltage,and charging time.
