48v 30A Electricity Saving Industrial Portable Charger For MHE Fork Lift
Product Details
| Type: | Portable Battery Charger | Technology: | Single Chip Microcomputer |
|---|---|---|---|
| Application: | Fork Lifter | Measurement: | Long * Wide * High ：349*227*188 (mm) |
| Output Maximum Current(A): | 30 | Maximum Power Point(W): | 1800 |
| Highlight |
high frequency battery charger,fork lift battery charger |
||
Product Description
High-Frequency Industrial Battery Charger
Application: Fork Lift(48v)
Model Name: ESCH48V30A-O
Product Parameters
| Model | ESCH48V30A-O | |
| Dimensions (mm) | Long * wide * high :349*227*188 (mm) | |
| Output maximum current (A) | 30 | |
| Maximum power point (W) | 1800 | |
| Input voltage (VAC) | 220V±15% | |
| Output voltage (VDC) | Lead-acid battery:63V; VRLA:60V;(Customizable) | |
| Applicable battery voltage | 48V lead-acid battery pack, (Customizable) | |
| Maximum efficiency | 93% | |
| Output voltage regulation precision | ±1% | |
| Output current accuracy | ±1% | |
| Working temperature | -30℃～-45℃ | |
| Classes of seismic measure | SAEJ1378 | |
| Cooling mode | Airblast cooling | |
| Over temperature protection | 75℃±5 | |
| Input under-voltage protection (VAC) | Under-voltage point 90V | |
| Output over-voltage protection (VDC) | 31V±1 | |
| Output over-current protection (A) | >110%*Maximum charge current | |
| Output short circuit protection | When the output is short circuited, charger shutdown, and automatic recovery after short-circuit solved. | |
| Battery reverse protection | Charger shutdown and alarm when the wire is connected reversely, it will automatically resume after wiring correctly. | |
Product Specification
- Charger integrates active power factor correction (PFC), can achieve zero pollution of the power grid and avoid the impact of large current grid;
- The input voltage range is very wide, AC185V-AC264V, suitable for any region’s voltage level of the world, has a great convenience for the power grid fluctuations and vehicle exports.
- The efficiency is very high, can reach more than 93%, the traditional charger can only reach about 80%.
- The intelligent temperature compensation function of the charging process can avoid the damage caused by the overcharge or under the charge of the battery, and the service life of the battery can be prolonged.
- Do the internal charger seismic processing, seismic grade up to SAEJ1378, fully meet the electric vehicle-using standard.
- Use the LLC resonance technology, whole charging process working under soft-switching condition, with less heating of the whole machine.
- (48-volt industrial battery charger)
Product Characteristics
- Single-Chip Microcomputer (SCM) according to the lead-acid batteries tolerance current capacity, life curve, gas analysis point and other information to complete the full charge of the whole process;
- With the environmental temperature compensation function, to ensure that the temperature of the weather conditions, can automatically resist over-charge and under-charge;
- With pulse charging function, the battery is filled with the premise of ensuring the best life of the battery；
- After three paint processing and dustproof design, the reliability of the operation is improved;
- With digital display function, can display online charging current, voltage, charging time;
- (48-volt industrial battery charger)
Product Strength
- Long life expectancy and proven in service record
- Designed for use in harsh conditions
- Smart modular design for simple and cost effective
- Highest efficiency, up to 97%
- Fast and simple installation, plug and play
- Cost effective spare parts philosophy
- Large range of chargers to match your application and optimize efficiency
Packaging & Delivery
Packaging Details:
Cartons,
Delivery Detail:
In 7 to 15 days against the order confirmation and deposit.
