HPT25i i-Hybrid Material Handling Truck 2500kg Heavy Duty Electric Manual Dual Mode
Product Details
| Load Capacity: | 2500KG | Drive Motor: | 0.75kW Brushless |
|---|---|---|---|
| Controller Type: | I50 | Charger: | 48V/5A |
| Highlight |
heavy duty electric pallet truck,dual mode material handling truck,2500kg manual electric pallet jack |
||
Product Description
HPT25i i-Hybrid Material Handling Truck
HPT25i Core Specifications
| Item | Specification | Unit |
|---|---|---|
| Rated Load Capacity | 2500 (5500lbs) | kg |
| Load Center | 600 (24") | mm |
| Wheelbase | 1272 (50.1") | mm |
| Minimum Turning Radius | 1422 (56") | mm |
| Overall Height | 587 (23.1") | mm |
| Lowered Fork Height | 80 (3.15") | mm |
| Max Lift Height | 200 (8") | mm |
| Tiller Arm Height Range | 560 - 1280 (22" - 50.4") | mm |
| Ground Clearance | 27 (1.1") | mm |
| Fork Size (L×S×e) | 1150/1220×52×160 (45"/48"×2.05"×6.3") | mm |
| Aisle Width (1000×1200 Pallet, Crossways) | 1980 (78") | mm |
| Aisle Width (800×1200 Pallet, Crossways) | 1880 (74") | mm |
| Drive Motor | 0.75kW Brushless | - |
| Lift Motor | 0.65kW | - |
| Travel Speed (Loaded/Unloaded) | 4.2/4.5 (2.6/2.8mph) | km/h |
| Max Gradeability (Loaded/Unloaded) | 6%/20% | - |
| Service Brake | Electromagnetic | - |
| Controller Type | i50 | - |
| Battery | 48V/15Ah LFP (48V/20Ah optional) | - |
| Charger | 48V/5A | - |
Universal Core Advantages
| Advantage Category | Core Features |
|---|---|
| Dual-Mode Switching | Electric/manual drive & lift convertible; Patented clutch technology; Zero operational downtime; 30 mins extra uptime |
| High-Efficiency Power System | 0.75kW brushless drive motor (higher efficiency, cost saving); 0.65kW lift motor; Hybrid pump for efficient electric lift |
| Reliable Battery & Charging | 48V LFP battery (free maintenance); 2-3 hrs fast charging; 80% capacity after 2000 cycles; 48V/20Ah larger capacity optional |
| Intuitive Operation & Display | Standard OLED screen (running hours, battery level, fault code display); Optional 2.5" hi-res I-Touch Screen (customizable, one-click VNA mode); One-touch Turtle/Upright Mode; Direct fault diagnosis |
| Safe & Humanized Design | Electromagnetic service brake; Secure password setting; Real-time slope degree display; 560-1280mm adjustable tiller arm; Pedestrian operation mode |
| Flexible Customization | Optional stainless steel model, scaled model, galvanized model; Optional I-Touch Screen handle; Adapts to various special working environments |
| Long Continuous Operation | 8 hrs non-stop working with a spare battery; Compact and portable charger; Meets long-hour material handling demands |
Company Service
Product Highlights
HPT25i i-Hybrid Material Handling Truck The HPT25i is a high-performance i-Hybrid material handling truck designed for medium and heavy-duty material handling with a 2.5-ton load capacity, featuring a pedestrian operation mode and electric/manual dual-mode drive & lift system. Leveraging patented ...
