19 Holes Polyester Fiber Gauntlet for Lead-acid Battery Tubular Woven and Non-Woven Gauntlet PT Bag

19 Holes Polyester Fiber Gauntlet for Lead-acid Battery Tubular Woven and Non-Woven Gauntlet PT Bag

Large Image :  19 Holes Polyester Fiber Gauntlet for Lead-acid Battery Tubular Woven and Non-Woven Gauntlet PT Bag

Product Details:
Place of Origin: China
Brand Name: LAKER
Certification: CE
Model Number: 6.6*19
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Carton
Delivery Time: within 7 days
Payment Terms: T/T
Supply Ability: 500000 pcs per month
Detailed Product Description
Pipe Diameter: 6.6mm Number Of Pipes: 19
Length: Customizable Center Distance: 7.2

Product Details

Material Applicable Devices
Woven  Paste Extrusion Equipment
Non Woven Powder Filling Equipment


19 Holes Polyester Fiber Gauntlet for Lead-acid Battery Tubular Woven and Non-Woven Gauntlet PT Bag 0


Type Battery Gauntlet/ PT bag
Application Traction battery, stationary battery, EV battery
Material textile
Color yellow, white
ER <=0.0035
Porosity >=58



Polyester/Woven Gauntlet Production Process
  1. Weave polyester yarn into fabric.
  2. Dip the polyester fabric in glue and dry it.
  3. Form the manifold with a tube drawing machine.
  4. Cut to required dimensions per customer request.

19 Holes Polyester Fiber Gauntlet for Lead-acid Battery Tubular Woven and Non-Woven Gauntlet PT Bag 1 19 Holes Polyester Fiber Gauntlet for Lead-acid Battery Tubular Woven and Non-Woven Gauntlet PT Bag 2

19 Holes Polyester Fiber Gauntlet for Lead-acid Battery Tubular Woven and Non-Woven Gauntlet PT Bag 3

Product Strength

Our gauntlet adopts the advanced textile and curing technology with 1 million square meters production capability.

The terylene gauntlet has advantages: lower electrical resistance, higher porosity, higher mechanical strength, higher anti oxidation, higher stability and elastic control.

It is widely used in traction battery, stationary battery and EV battery, it can meet the requirements for the oxide filling and paste filling processes.


ER <= 0.0035
Porosity % >=58
Tensile strength(N/cm) >=390
Detoration under force(N) >=36
Acid resistance >=0.7
Content of CI <=0.003
Reductive KMnO4 <=12
Weight loss after soaking in acid <=1.50-0.30
