Portable Loading Dock Ramps DCQ10-0.7 10 Ton Fixed Hydraulic Dock Leveler
Product Details
| Type: | Fixed Hydraulic Dock Ramp | Loading Capacity: | 10000 Kgs |
|---|---|---|---|
| Power: | 0.75KW | Model: | DCQ10-0.7 |
| Brand: | LAKER | Platform: | Customized |
| Highlight | Hydraulic Dock Ramp, Hydraulic Dock Plate | ||
Product Description
Product introduction
| Type | Fixed Hydraulic Dock Ramp |
| Model | DCQ10-0.7 |
| Loading Capacity | 10000 kgs |
Fixed hydraulic dock ramp is an auxiliary equipment for forklift/truck/van to load and unload goods quickly.
The forklift/truck/van can drive into carriage directly from ground to load and unload the goods.
It is helpful to reduce labor work and multiple increase the work efficiency.
Product parameters
| Model |
Capacity load (kg) |
Platform Size(mm) |
Lip (mm) |
Travel(mm) |
Power (kw) |
Pit size(mm) | |||
| Upper | Lower | L | W | H | |||||
| DCQ6-0.55 | 6000 | 2000*2000 | 400 | 300 | 250 | 0.75 | 2060 | 2040 | 600 |
| DCQ6-0.7 | 6000 | 2500*2000 | 400 | 400 | 300 | 0.75 | 2560 | 2040 | 600 |
| DCQ8-0.55 | 8000 | 2000*2000 | 400 | 300 | 250 | 0.75 | 2060 | 2040 | 600 |
| DCQ8-0.7 | 8000 | 2500*2000 | 400 | 400 | 300 | 0.75 | 2560 | 2040 | 600 |
| DCQ10-0.55 | 10000 | 2000*2000 | 400 | 300 | 250 | 0.75 | 2060 | 2040 | 600 |
| DCQ10-0.7 | 10000 | 2500*2000 | 400 | 400 | 300 | 0.75 | 2560 | 2040 | 600 |
Product display
Product characteristics
The stationary yard ramp is operated easily with electricity and hydraulic power. It is classified to five kinds by carrying-weight capacity, such as 6T, 8T, 10T, 12T, 15T etc.
2. Stationary yard ramp also can according to different models and the loading process of the change in the car, automatically adjust the height.
3. Introduction of foreign advanced technology manufacturing hydraulic system, reliable.
4. This product according to the different needs of the users, in terms of dimensions does special design to withstand loads.
