Heavy Duty 400 Ton Forklift Tyre Press Machine For Solid Tire Loading / Unloading On Sale
Product Details
| Type: | Solid Tire Press Machine | Capacity: | 400 Tons |
|---|---|---|---|
| Model: | TP400 | Weight: | 4000kgs |
| Size: | L2770xW850xH2880 Mm | Brand: | LAKER |
| Motor: | 15KW | Color: | Blue,Yellow, Silver |
| Warranty: | Accessories Lifetime Warranty | Voltage: | 220V/380V Customized |
| Work Hydraulic: | 30Mpa | Max Tire Size: | 25 Inches |
| Highlight | Forklift Tyre Press Machine, Solid Tire Press Machine | ||
Product Description
Product display
| Model | TP400 |
| Nominal pressure | 4.0 MN |
| Work hydraulic | 30 Mpa |
| Max Tire Size | 25 Inches |
| Max Cylinder Stroke | 900 mm |
| Motor | 15 KW |
| Oil Tank Capacity | 90 L |
| Size | L2770xW850xH2880 mm |
| Weight | 4000 kg |
4.0MN solid tyre pressing machine is a special equipment for solid tire loading and unloading,
It can also apply to the tyres below 25".
This machine is a frame type structure.The hydraulic cylinder is located above the piston movement from top to bottom, the department. Platform, fixed on the piston rod and spherical pressure box, firm structure, is made of high-quality materials carefully assembled, so good performance. With the electric control box independent.
The hydraulic system of the machine consists of hydraulic system and hydraulic system of the auxiliary machine. This machine hydraulic system is composed of the high-pressure pump, solenoid valve, pressure relief valve, check valve, pressure indicator and oil cylinder.
High pressure relief valve is the oil pressure setting of high pressure pump, its maximum setting value is 30MPa.
Product display
Product features
- Heavy duty frame: The construction is welded by large-scale beam and channel beam.
- High-grade Hydraulic Cylinder: The biston rod is grinded and hard-chromium plated.
- Easy pull and press into the rims.
- Voltage and phase customized according to different power supply.
