Product Details:
|
| Type: | Solid Tire Press Machine | Model: | TP160 |
|---|---|---|---|
| Capacity: | 160Tons | Weight: | 2000 Kgs |
| Size: | L2110xW800xH2300 Mm | Brand: | LAKER |
| Motor: | 5.5KW | Warranty: | Accessories Lifetime Warranty |
| Work Hydraulic: | 21.5Mpa | Voltage: | 220V/380V Customized |
| Max Tire Size: | 16Inches | Origin: | China |
| High Light: | Disassembling Solid Tire Press Machine,Dual Station Tire Press Machine,160Tons Tire Press Machine |
||
Product specifications
| Detailed Product | Description | |
| Model | TP160 | |
| Capacity | Tons | 160 |
| Max. Tire Diameter | inches | 20'' |
| Total Length | mm | 2100 |
| Total Width | mm | 800 |
| Total Height | mm | 2400 |
| Plate diameter(inside-outside) | mm | 530-640 |
| Work space width | mm | 1600 |
| work platform ret height | mm | 350 |
| Operating Pressure | MPa | 21.5 |
| Cylinder Max.stroke | mm | 650 |
| Oil Tank Capacity | Liters | 90 |
| Electro-Motor | kw | 5.5 (380v) |
| Weight | kgs | 2000 |
| Press Speed/time | min | 2 |
|
Remarks: |
mount and dismount rim size 8inch to 16inch, lifting platform is optional, customization is acceptable. | |
| TOOL-I (press frame) |
8-9〃, 10-12〃, 15〃 17'', 20'' one for each |
applicable for rim 8''-20'' |
| TOOL-II (Press barrel) | 10〃, 12〃, 15〃, 17'', 20'' one | applicable for rim 8''-20'' |
| TOOL-III (guide ring) | 12〃, 15〃, 20〃one for each | applicable for rim 8''-20'' |
| TOOL-IV (backing ring) |
10〃, 8-9〃, 12 〃, 15〃 17'', 20'' one for each |
applicable for rim 8''-20'' |
| TOOL-V (guiding rod) | optional | |
Product display
Product strength
1. Efficient and accurate tire pressure monitoring
2. Quick and easy inflation and deflation of tires
3. Durable construction for long-lasting use
4. Versatile and compatible with a wide range of tire sizes
5. User-friendly interface with customizable settings and presets
Production
Product features
Free protection kit
Usage method forklift tire press machine
First of all, choose a good tooling correctly, put the mold on the work table, and then put the wheel on the mould, handling pressure head to Press the die on the tire and finally with the boot ring loaded. Different types of tyres and wheels need different tooling, the user to install the tire before the selection of tooling, then the disassembly and assembly operations, it will be very convenient and quick. According to the motion mode and the size of the machine, the machine can be divided into manual press and electric press, which is generally suitable for large tonnage forklift truck or truck tire.
Packaging
About us
LAKER AUTO PARTS CO., LIMITED is ONE-STOP-SHOP offering parts and accessories for forklifts trucks, low-speed electric vehicles, and auxiliary material handling equipment with a guaranteed high-performance product at the most competitive price.
Our core products are as follows:
1. Lead acid Batteries for Electric forklift trucks and Electric vehicles,
2. Intelligent automatic battery chargers including industrial frequency and high frequency,
3. Regular black and non-marking solid tires for forklifts used at small working fields and warehouses,
4. Hydraulic solid tire press machine for mounting and dismounting the solid tires,
5. Mobile loading ramp and fixed dock leveler for loading the container and goods,
6. Low-speed Electric vehicle with loading platform 1Ton to 3Ton for warehouse/airport/port dock material delivery.
and various of battery accessories for application of maintenance and replacement. (Such as 7. battery plates, gauntlets, connectors, battery watering systems, battery safety valves, battery vent plugs, battery cables and etc.)
7. Many different kinds of golf cart and sightseeing vehicles
At LAKER, we are dedicated to providing comprehensive, quality service from the initial quotation to final product delivery.
Our commitment to service, knowledge, and product availability has made us a One-Stop-Shop for our customers and their business needs.
All the Forklift relevant products are selected from top-class manufacturers under their own brand MYING and LAKER, supported by skilled technicians on standby for any technical query online or solution after-market.
LAKER sincerely hopes to be your best choice for the power solution and maintenance of the Forklift!
We will devote ourselves to enriching our product catalogs with more environment-friendly maintenance products for material handling equipment in the near future.
Given chance and full space, we would show you all of our advantages and let us grow up together. We are sure we can establish a long-term and friendly business relationship with your esteemed company
