Matched Positive Negative Take-Off Cable Pair 50mm² Copper Conductor Rubber Jacket Custom Length
Product Details
| Type: | Forklift Battery Soft Cable | Model: | LK-Outcable-50 |
|---|---|---|---|
| Color: | Black | SQMM: | 50mm2 |
| Material: | Rubber, Copper | Application: | Forklift Battery Connection |
| Certificate: | CE | Centre Length: | Customized |
| Model: | LK-Cable-95 | SQMM: | 95mm2 |
| Sales Unit: | Pair (positive + Negative, 2 Pcs) | ProbeKey: | Probe1 |
| Highlight | Battery Terminal Cables, Custom Battery Cables | ||
Product Description
LAKER LK-Outcable-50 | 50mm² Take-Off Cable Positive and Negative Pair
The pair of leads that carries current between the battery connector and the truck or charger, supplied matched so both sides of the run are the same. 50mm² copper conductor, black rubber jacket, centre length cut to your charging bay measurement.
| Item | Detail |
| Model | LK-Outcable-50 |
| Section | 50mm² |
| Conductor | Flexible stranded copper |
| Jacket | Black rubber, acid mist and abrasion resistant |
| Centre length | Customized to the truck and charger layout |
| Ends | Battery connector and equipment stud, to drawing |
| Application | Battery to truck connector take-off run on electric forklifts |
| Brand / origin | LAKER / China |
| Certificate | CE |
Why This Is a Take-Off Cable, Not a Cell Link
A cell link sits inside the battery box, short and fixed, and it never moves once the pack is assembled. A take-off cable does a different job: it runs from the battery connector out to the truck or charger, often several metres, and it is dragged, coiled, hung on a hook and dropped on the floor every shift. The service life of the two leads is decided by completely different things, which is why LAKER keeps them as separate models instead of quoting one cable for both positions.
For a 50mm² lead the take-off run is the normal choice on standard electric counterbalance and reach trucks. Where the charger sits far from the parking bay, the length matters more than the section, and both are made to your measurement.
Model Range
| Model | Section | Position |
| LK-Cable-25 | 25mm² | inside the pack, light duty |
| LK-Cable-35 | 35mm² | inside the pack, standard duty |
| LK-Outcable-50 | 50mm² | battery to truck connector, take-off run |
| LK-Cable-70 | 70mm² | heavy traction packs |
Take-Off Cable Wear
A take-off cable fails in three places, and all three come from handling rather than from current. The first is the joint where the jacket meets the lug, which stiffens and cracks when the lead is lifted by the cable instead of the connector. The second is the middle of the run, where the lead is run over a kerb or a metal edge and the jacket is worn through. The third is the connector end, where repeated plugging loosens the termination.
A rubber jacket resists acid mist and oil better than a thin PVC sleeve, which is why this cable is specified in rubber. If the run crosses a traffic area, add a cable protector rather than relying on the jacket alone.
Installation Notes
Give the cable a support at both ends so the weight does not hang on the termination, keep the bend radius generous at the cabinet entry, and make sure the connector is fully seated before charging starts. A partly seated connector on a 50mm² lead heats quietly and is usually found only when the plastic around it has already softened.
FAQ
| Can the length be customized? | Yes, the centre length is produced to your charging bay measurement. |
| Which connector is supplied? | To your drawing: charger stud, ring lug or battery connector type. |
| Is it suitable for indoor charging areas? | Yes; the rubber jacket is chosen for acid mist and oil exposure. |
| Is it CE certified? | Yes. |
Supply and Service
Centre length and end fittings are confirmed before production, cables are inspected in-house before packing, and technical questions during an order are answered online. After-sales support continues once the leads are in service.
Packing
Take-off leads are coiled to a radius the cable can hold without taking a set, with the connector protected so it arrives round rather than deformed.
Product Highlights
LAKER 50mm² take-off cable pair for forklift batteries: matched positive and negative leads, acid resistant rubber jacket, custom centre length.
