High Frequency 24v 25-30A Industrial Portable Charger With Handle

China High Frequency 24v 25-30A Industrial Portable Charger With Handle supplier
High Frequency 24v 25-30A Industrial Portable Charger With Handle supplier High Frequency 24v 25-30A Industrial Portable Charger With Handle supplier

Large Image :  High Frequency 24v 25-30A Industrial Portable Charger With Handle

Product Details:

Place of Origin: China
Brand Name: LAKER
Certification: ISO9001,CE, UL
Model Number: ESCH24V25A-OP ESCH24V30A-OP

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton, Standard Wooden Pallet
Delivery Time: 20 days After Order Confirmation and Deposit
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Type: High Frequency Portable Charger Application: Forklift, Pallet Jack Battery
Model: ESCH24V30A-OP Technology: SCM
Material: Steel Box OEM: Yes



MHE High-Frequency Industrial Battery Charger



Model Name: ESCH24V25A-OP  ESCH24V30A-OP





Product Parameters



Model ESCH24V25A-OP ESCH24V30A-OP
Dimensions (mm) Long * wide * high:353*204*172 (mm)
Output maximum current (A) 25 30
Maximum power point (W) 750 900
Input voltage (VAC) 100V~264V
Output voltage (VDC) Lead-acid battery:31V; VRLA:29.4V;(customizable)
Applicable battery voltage 24V lead-acid battery pack, (Customizable)
Maximum efficiency 93%
Output voltage regulation precision ±1%
Output current accuracy ±1%
Working temperature -30-45
Classes of seismic measure SAEJ1378
Cooling mode Air blast cooling
Over temperature protection 75±5
Input under-voltage protection (VAC) Under-voltage point 90V
Output over-voltage protection (VDC) 31V±1
Output over-current protection (A) >110%*Maximum charge current
Output short circuit protection When the output is short-circuited, charger shutdown, and automatic recovery after short-circuit solved.
Battery reverse protection Charger shutdown and alarm when the wire is connected reversely, it will automatically resume after wiring correctly.



Product  Application

  • Charger integrates active power factor correction (PFC), can achieve zero pollution of the power grid and avoid the impact of large current grid;
  • The input voltage range is very wide, AC100V-AC264V, suitable for any region’s voltage level of the world, have a great convenience for the power grid fluctuations and vehicle exports.
  • The efficiency is very high, can reach more than 93%, the traditional charger can only reach about 80%.
  • The intelligent temperature compensation function of the charging process can avoid the damage caused by the overcharge or under the charge of the battery, and the service life of the battery can be prolonged.
  • Do the internal charger seismic processing, seismic grade up to SAEJ1378, fully meet the electric vehicle-using standard.
  • Use the LLC resonance technology, whole charging process working under soft-switching condition, with less heating of the whole machine.
  • (industrial battery charger price, maintenance-free battery charger)



Product Characteristics



  • Single Chip Microcomputer (SCM) according to the lead-acid batteries tolerance current capacity, life curve, gas analysis point and other information to complete the full charge of the whole process;
  • With the environmental temperature compensation function, to ensure that the temperature of the weather conditions, can automatically resist over-charge and under-charge;
  • With pulse charging function, the battery is filled with the premise of ensuring the best life of the battery;
  • After three paint processing and dustproof design, the reliability of the operation is improved;
  • With digital display function, can display online charging current, voltage, charging time;
  • (industrial battery charger price, maintenance-free battery charger)



Packaging & Delivery



High Frequency 24v 25-30A Industrial Portable Charger With Handle

Packaging Details:

Cartons, Pallets



Delivery Detail:

In 7 to 15 days against the order confirmation and deposit.
